Patriot® Fully Framed Turnout Lockers

The key to any turnout locker is the ability to grab and go. The Patriot Turnout Locker puts everything from flight gear to EMS equipment within reach. The Patriot Fully Framed Turnout Locker shares the same heavy-gauge steel construction as the Gear and Duty lockers but have an open front and smooth frame, allowing users to retrieve equipment in a flash.

Distinguishing Features:

  • True fully framed construction offers better rigidity
  • 4 or 6 inch high Channel Base available
  • Offered in KD or Welded construction
  • Order Welded for factory assembled locker
  • Open front and hemmed frame
  • 24 inch deep available in 18, 24, 30, 36, 42, or 48 inch widths
  • 18 inch deep locker available in 18 or 24 inch widths
  • Available in 72 or 78 inch heights
  • Number plates mount to the shelf face for easy visibility

Please Note: Patriot accessories are designed for attachment on-site during locker assembly and installation. On welded Patriot models, only the hat shelf will be factory installed. This is done to optimize paint coverage and facilitate interior configuration changes if needed.

  • 1135
  • 1132
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers
  • Patriot® Fully Framed Turnout Lockers

In response to the needs of first responders everywhere for heavy duty, purpose-built storage, we are proud to offer a special line of gear and turnout lockers designed with the unique demands of armed forces personnel and emergency response professionals in mind.

Patriot Turnout Lockers are a mission-specific group of tactical locker products with a load of upgraded accessories. They are designed to serve and designed to last. Patriot Lockers start with heavy gauge, cold-rolled steel and are painted using a durable yet attractive powder coat finish. Working from that solid foundation, we’ve designed premium knocked down and fully welded 24”, 30”, 36”, 42” and 48” wide lockers and a list of accessories that allow the locker to be fitted out for any kind of duty.

Turnout lockers give you the advantage of instant access to mission gear, and Patriot accessories like drawers, security boxes, or footlockers give you secure storage for items that are best kept under lock and key.


Whether the Patriot you specify has doors or not, the same flexibility is built into each one. Gear and Turnout accessories are designed for use in either type locker.


Balance the advantage of an open front locker with secure storage by adding one of the two sizes of security box, drawers or a footlocker.

Patriot® Turnout Locker - 18" and 24" Deep

Size

KD (Knocked Down) Construction

All-Welded  Construction

With 15" Deep Shelf

Width

Depth

Height

Cat. No.

Height

Cat. No.

18"

18"

72"

6KTDA84

76"

6WTDA84C

24"

18"

72"

6KTDA04

76"

6WTDA04C

30"

18"

72"

6KTDA14

76"

6WTDA14C

36"

18"

72"

6KTDA24

76"

6WTDA24C

24"

24"

72"

6KTDA00

76"

6WTDA00C

30"

24"

72"

6KTDA10

76"

6WTDA10C

36"

24"

72"

6KTDA20

76"

6WTDA20C

42"

24"

72"

6KTDA30

76"

6WTDA30C

48"

24"

72"

6KTDA40

76"

6WTDA40C

With 21" Deep Shelf

Width

Depth

Height

Cat. No.

Height

Cat. No.

18"

24"

72"

6KTDA82

76"

6WTDA82C

24"

24"

72"

6KTDA02

76"

6WTDA02C

30"

24"

72"

6KTDA12

76"

6WTDA12C

36"

24"

72"

6KTDA22

76"

6WTDA22C

42"

24"

72"

6KTDA32

76"

6WTDA32C

48"

24"

72"

6KTDA42

76"

6WTDA42C

Color NumberColor NameColor
054Canvas
021Gray Ash
028Gray
073Champagne
723Light Putty
012Tawny Tan
701Spray Green
952Turquoise Teal
055Shamrock
812Hunter Green
715Lake Blue
823Slate Blue
806Marine Blue
052Reflex Blue
822Regal Blue
058Nordic Purple
056Sunburst
710Sagebrush Yellow
720Mandarin Orange
722Patriot Red
767Cardinal Red
736Burgundy
848January White
949Jet Black

NOTE: Colors shown are as close to actual finishes as the printing process allows. Do not make your final color selection based on the color shade shown on this page. Penco Color Charts are available for a more accurate color match. Exposure to high humidity, chlorine salts, abrasive cleaners, germicidal cleaners and acids can damage the finish and will void the guarantee. For outdoor applications or other harsh environmental conditions, contact your Penco Representative.
